Research in the Schulz Laboratory

Natural Product Research:

Engineered natural product biosynthesis and metabolomics as tools to identify and access novel bioactive compounds.

The Schulz group pursues different projects to break up important limitations in current natural product research. Both the limited availability and derivatization of different compounds are addressed, rendering new compounds with diverse biological activities available.

Naturstoff Forschung Natural Products Research - Schulz Laboratory Ruhr-Universität Bochum Polyketide Terpene Terpenoids

Microbial Synthesis

Polyketides form a large family of natural products and many polyketides are applied for the treatment of diseases such as cancer or infections.[1] However, the large and polyfunctional structures of many polyketides complicate the derivatization that is required to develop them into clinically useful compounds. Biosynthetic pathways show an enormous capability of generating molecular complexity. Genetic engineering of polyketide-producing bacteria is thus used to direct the biosynthetic derivatization of polyketides, yielding compounds with altered biological activities.

Polyketide Derivatization Polyketid Derivatisierung  - Schulz Laboratory Ruhr-Universität Bochum





























Via site-directed mutagenesis of key enzymes from the biosynthetic pathway, predictable redox derivatives of the parent compound pre-monensin are synthesized in the bacterium Streptomyces cinnamonensis.

Artificial Functionalization of Natural Products

Biosynthetic pathways bring about structural complexity but are inflexible in comparison to

synthetic organic chemistry. The introduction of synthetic compounds into biosynthetic pathways combines the strength of both regimes. In precursor-directed mutasynthesis, synthetic compounds are accepted by wild-type enzymes from a native producer organism and can carry artificial functional groups into the

corresponding compound.

Polyketide Derivatization Extender Units Malonate Precursor directed biosynthesis mutsynthesis - Schulz Laboratory Ruhr-Universität Bochum











Cultures of Streptomyces cinnamonensis yield specifically modified derivatives of pre-monensin when supplied with the synthetic malonic acid derivatives shown here.


In many cases, enzymes from the biosynthetic reaction cascade do not accept a synthetic

building block as substrate and the intended modified biosynthesis fails. We recently introduced the enzyme-directed mutasynthesis as a concept to engineer the substrate specificity of key enzymes from polyketide biosynthesis facilitate the acceptance of malonic acid-based building blocks into a natural

product. In a first study, organic synthesis, enzyme engineering and fermentation technology are combined towards the derivatization of the antibiotic erythromycin A.

Polyketide Derivatization Extender Units Malonate Precursor directed biosynthesis mutsynthesis Erythromycin - Schulz Laboratory Ruhr-Universität Bochum















In enzyme-directed mutasynthesis, engineered enzymes are utilized inside a microbial producer to accept synthetic building blocks as substrates for the targeted derivatization of a natural product, in this case the antibiotic erythromycin.



Limitations of biosynthesis are thus broken up by enzyme engineering. A logical extension of this is the partial synthesis of further derivatives. These synthetic efforts start from compounds obtained through engineered biosynthesis and as well directly from interesting natural products for projects within medicinal

chemistry to identify new molecules with interesting antibacterial or anti-tumor activities.

Heterologous Fermentation of Terpenes

In many cases, natural sources do not provide enough material to investigate the promising biological activity of natural products. This is particularly true for members of the terpenoids family of natural products. We express key enzymes towards terpenes in baker’s yeast to synthesize preparative amounts of the corresponding compounds in synthetically meaningful quantities.

Heterologous Fermentation of Terpenes

In many cases, natural sources do not provide enough material to investigate the promising biological activity of natural products. This is particularly true for members of the terpenoids family of natural products. We express key enzymes towards terpenes in baker’s yeast to synthesize preparative amounts of the corresponding compounds in synthetically meaningful quantities.

heterologous terpene fermentation in yeast - Fusicoccin A - Fusicoccadiene  - Schulz Laboratory Ruhr-Universität Bochum



































Baker’s yeast is genetically engineered to produce fusicoccadiene (FCdiene) from the fungus Phomopsis amygdali. It carries several mutations in its primary metabolism (mevalonic acid pathway) to channel biosynthetic capability towards the targeted compound.
